Underwater Camera
Feedback Form

Underwater Camera

This underwater camera is suitable for working in the water at the maximum depth of 30 meters. It varies in different types, like DV-984EH and DV-984VH.

Features
1. This product exerts excellent performance under any circumstances.
2. It can work for 24 hours surveillance with the optical multi-coating filter based on the IR LED and CCD.
3. The monitoring distance of the IR LED light reaches over 10m.
4. The CDS cell controls the LED switching automatically to detect the ambient light condition.
5. Made of aluminum material, the underwater camera is designed with anticorrosion surface that can resist rust for a long time.

Picture Underwater Camera Underwater Camera
Model number DV-984EH DV-984VH
Image Sensor 1/3" SONY EFFIO 1/3" SONY
Picture Element 1020(H) x 596(V) 976(H) x 596(V)
TV System NTSC /PAL NTSC /PAL
Scanning Frequency 15,734KHz(H), 59,94Hz(V)
15,625KHz(H), 50Hz(V)		 15,734KHz(H), 59,94Hz(V)
15,625KHz(H), 50Hz(V)
Scanning System 2:1 interlace 2:1 interlace
Synchronization System Internal Sync Internal Sync
Resolution (Horizontal) 700TVL 600TVL
Video Output 1Vpp 75ohm Composite 1Vpp 75ohm Composite
S/N Ratio More Than 52db (AGC-OFF) More Than 52db (AGC-OFF)
Min. Illumination 0.01Lux / 0LUX (IR On) 0.3Lux / 0Lux (IR On)
Auto Electronic Shutter 1/60 ~ 1/100,000 sec. 1/50 ~ 1/100,000 sec. 1/60 ~ 1/100,000 sec. 1/50 ~ 1/100,000 sec.
White Balance AUTO AUTO
IR LED 12PCS 12PCS
Lens BOARD LENS 6mm BOARD LENS 6mm
Power Source DC 12V +- 10% DC 12V +- 10%
Power Consumption DC 12V 250MA DC 12V 250MA
Ambient temp -10°C ~+60°C -10°C ~+60°C
Dimensions 69.7(W)*67.2(H)*110(L) 69.7(W)*67.2(H)*110(L)
Length of cable 30M 　
Weight 1.5KG 　
